Calf box

  • stable,hot dip-galvanised metal frame
  • GRP base grille (two-part) offering excellent grip and anti-slip properties
  • easy-to-clean side walls made from PVC panels with smooth surface
  • revolving door which opens in both directions
  • includes a watering bucket mounting bracket and two foldable bucket brackets
  • Feeding places can be individually blocked
  • folding handle on the front make moving it exceptionally easy
  • transport device optionally available
  • Can be transported with pallet forks
  • roof optionally available
  • Bucket not included
  • Comes disassembled
Local animal protection regulations must be observed.
Items
Ref. no.DescriptionPUPallet
14610Calf box small116 PAL6 PAL
14611Calf box large116 PAL6 PAL


Technical data
14610
External dimensions173 cm x 93 cm x 131 cm
Interior dimensions130 x 85 x 106 cm
Weight121 kg
14611
External dimensions201 cm x 107 cm x 131 cm
Interior dimensions160 x 100 x 106 cm
Weight160 kg
Technical data1461014611
External dimensions173 cm x 93 cm x 131 cm201 cm x 107 cm x 131 cm
Interior dimensions130 x 85 x 106 cm160 x 100 x 106 cm
Weight121 kg160 kg

Preview imageItem. No.Description1461014611
 14605-12Handle for 14610xx
 14605-13Locking Rodxx
 14605-14Bucket Ring for Calf Boxxx
 14605-15Screw Set f. Frame 14610 x
 14605-16Wheelsetxx
 14605-18Screw Set Dxx
 14605-19Front Framex
 14605-2Front Frame x
 14605-21Horizontal Brace for 14610x
 14605-22Frame Backx
 14605-23Door for 14610x
 14605-29Screw Set Package Ax
 14605-4Horizontal Brace for 14611 x
 14605-5Frame Back x
 14605-6Door for 14611 x
GRP Grille for Calf Box Small14610-1GRP Grille for Calf Box Smallx
GRP Grille for Calf Box Large14611-1GRP Grille for Calf Box Large x
Panel for Calf Box Mod. 201714611-2Panel for Calf Box Mod. 2017xx
Panel for Calf Box Mod. 201714611-3Panel for Calf Box Mod. 2017xx
 14605-47Spare Locking Rod right,xx
